PERFORMANCE FEATURE
- Air energy heat pump enclosed drying system, only drains water but not heat, no energy loss, 100% heat recovery;
- Use electric energy, no pollution, energy saving and environmental protection;
- Airtight dehumidification and drying, less damage to the material structure, can solve the problems of blasting and saccharification during baking;
- No sulfur after drying, the material has good quality and reducibility;
- Closed hot air circulation, strong wind convection, no ventilation dead angle in the drying room, good consistency;
- Accurate temperature and humidity can only be controlled in sections, programmable + LCD touch screen intelligent control, fully automatic operation;
- No need to flip the material during the drying process, saving labor.
Technical data:
|
Model |
SDJ-20DAABA |
SDJ-20XAABA |
SDJ-40DAABA |
SDJ-40XAABA |
SDJ-80DABBA |
SDJ-120DACBA |
SDJ-160DADBA |
|
Drying Temperature |
15℃~75℃ |
||||||
|
Dehumidification Capacity kg/h (return air temperature 45℃, humidity:65%RH) |
20 |
20 |
40 |
40 |
80 |
120 |
160 |
|
Rated power input Kw |
5.3 |
5.3 |
11.8 |
11 |
21.6 |
31.9 |
43.2 |
|
Auxiliary electric heating power Kw |
7.2 |
7.2 |
13.5 |
13.5 |
18 |
18 |
18 |
|
Air volume m3/h |
6100 |
6100 |
11100 |
11100 |
27900 |
37200 |
55800 |
|
Air way |
at the top |
at the bottom |
at the top |
at the bottom |
at the top |
at the top |
at the top |
|
Power supply |
380V / 3N / 50Hz |
||||||
|
Refrigerant |
R134a |
||||||
|
Functions |
Heat up, dihumidification, exhaust humidity |
||||||
|
Boundary dimension(length*width*height)mm |
910*950*1455 |
910*860*1505 |
1210*1060*1765 |
1210*1160*1715 |
1670*1210*1815 |
2100*1410*1965 |
2250*1510*1915 |
|
Unit weight |
245 |
230 |
390 |
370 |
850 |
1250 |
1680 |
